– The new successful Gaming Bronze series combines high performance with a low noise level and high effciency. The new DC/DC technology guarantees for increased efficiency and a maximum tension stability even during excessive gaming. Thanks to this high efficiency and the associated 80+ BRONZE certification high electricity costs are now a thing of the past. Six integrated safety ciruits provide for an all-time safe operation and the sleeved main cable harness ensures order in the PC case.
Features
– Extremely silent cooling: large 120mm fan
– Excellent air flow design for a better heat dissipation
– Full safety design:
• OVP (Over Voltage Protection)
• UVP (Under Voltage Protection)
• SCP (Short Circuit Protection)
• OPP (Over Power Protection)
– Low stand-by consumption
– High energy efficiency: 80+ BRONZE certified (complies with ErP2014 norm)
– Active-PFC
Technical data
General
– Peak Power (W): 850
– Form factor ATX 12V: Version 2.4
– Voltage (Vac): 200 – 240
– Model: Gaming | XP850R10
– Frequency (Hz): 50
– Input current (A): 10
– PFC: Active
Output
+3.3V (A): 20
+5V (A): 20
+12V1 (A): 70.8
-12V (A): 0.3
+5Vsb (A): 3.0
– Max. combined power 12V (W): 850
– Max. combined power 3.3V + 5V (W): 100
+12V2 (A): Yes
Fan / Cooling technology
– Bearing technology: Hydro Bearing
– Fan size (mm): 120
Protection
– OCP (over current protection): Yes
– OVP (over voltage protection): Yes
– UVP (under voltage protection): No
– SCP (short circuit protection): No
– OTP (over temperature protection): No
– OPP (over power protection): Yes
Eco / Efficiency
– 80 PLUS certification: 80+ Bronze
– Efficiency (%) at 230V, 20% load >85%
– Efficiency (%) at 230V, 50% load >88%
– Efficiency (%) at 230V, 100% load >85%
Environmental directives
– ErP
– WEEE
– RoHS
Cable management / Connectors
– Modular cable management: No
– Cable length to mainboard (mm): 500
– Cable length to first connector (mm): 450
– Maximum cable length (mm): 750
– Sleeved cables: No
– No. of cables: 7
– ATX-Motherboard (20+4-pin): 1
– P4+4 (CPU): 2
– P8 (CPU): No
– PCI-E 6-pin (GPU): No
– PCI-E 6+2-pin (GPU): 3
– PATA 4-pin: 3
– SATA 15-pin (HDD, Drives): 8
– FDD (Floppy): No
Logistics data, RRP
– Range: Gaming
– Article number: XN240
– EAN code: 4044953502712
– Dimensions, package (L x W x H), (mm): 140 x 150 x 86mm
– Gross weight, package (kg): 1.98
– Pieces per packaging unit: 8
– Dimensions, shipping box (L x W x H), (mm): 580 x 440 x 265
– Gross weight, shipping box (kg): 16.50
