Features
– Provides two methods of operation: Infrastructure and Ad-Hoc
– Adopts MIMO technology for wireless rates of up to 300Mbps
– Adopts CCA technology which automatically avoids channel conflicts using its channel selection feature
– Quick Secure Setup, complies with WPS for worry free wireless security
– Supports 64/128-bit WEP, complies with 128 bit WPA standard(TKIP/AES), supports MIC, IV Expansion, Shared Key Authentication, IEEE 802.1X
– Simple Configuration and monitoring
– Supports Roaming technology, guaranteeing efficient wireless connections
– Supports Windows 2000/XP/Vista/7
Specifications
– Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, CSMA/CA with ACK
– Wireless Signal Rates With Automatic Fallback:
* 11n: Up to 300Mbps (dynamic)
* 11g: Up to 54Mbps (dynamic)
* 11b: Up to 11Mbps (dynamic)
– Frequency Range: 2.4-2.4835GHz
– Wireless Transmit Power: 20dBm (max. EIRP)
– Modulation Type: OFDM/CCK/16-QAM/64-QAM
– Receiver Sensitivity:
* 270M: -68dBm@10% PER
* 130M: -68dBm@10% PER
* 108M: -68dBm@10% PER
* 54M: -68dBm@10% PER
* 11M: -85dBm@8% PER
* 6M: -88dBm@10% PER
* 1M: -90dBm@8% PER
– Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)
– Support Operating System: Windows 7 (32/64-bits), Windows Vista (32/64-bits), Windows XP (32/64-bits), Windows 2000
HARDWARE SPECIFICATION
– Interface: USB 2.0 Hi-Speed
– Antenna Type: Internal Omni-directional Antennas
– Certifications: CE, FCC
– Operating temperature: 0C-40C (32F-104F)
– Storage temperature: -40C-70C (-40F-158F)
– Relative humidity: 10%-90%, non condensation
– Storage Humidity: 5%-95% non-condensing
– Dimensions: 86×26×12 mm
