– 600 (433+150)Mbps wireless speed with 802.11ac
– A tiny way to get speedy next generation Wi-Fi connections
– Selectable Dual Band connections for lag-free HD video streaming and gaming
– Advanced Security: Supports 64/128 WEP, WPA, PA2/WPA-PSK/WPA2-PSK (TKIP/AES)
– Supports Windows 8/7/XP
HARDWARE FEATURES
– Interfaces: USB 2.0
– Dimensions (W×D×H): 41×19.5×8.7 mm
– Antenna Type: Omni Directional
WIRELESS FEATURES
– Wireless Standards:
* IEEE 802.11ac, IEEE 802.11a,
* IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
– Wireless Security: Support 64/128 bit WEP, WPA-PSK/WPA2-PSK, 802.1x
– Frequency: 5GHz, 2.4GHz
– Modulation Technology: DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM
– Signal Rate:
* 5GHz
11ac: Up to 433Mbps(dynamic)
11a: Up to 54Mbps(dynamic)
* 2.4GHz
11n: Up to 150Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
– Reception Sensitivity:
* 5GHz:
11a 6Mbps: -94dBm
11a 54Mbps: -78dBm
11n HT20 MCS0: -94dBm
11n HT20 MCS7: -77dBm
11n HT40 MCS0: -92dBm
11n HT40 MCS7: -74dBm
11ac VHT80 MCS0: -89dBm
11ac VHT80 MCS9: -64dBm
* 2.4GHz:
11b 1Mbps: -99dBm
11b 11Mbps: -91dBm
11g 6Mbps: -94dBm
11g 54Mbps: -77dBm
11n HT20 MCS0: -95dBm
11n HT20 MCS7: -76dBm
11n HT40 MCS0: -92dBm
11n HT40 MCS7: -73dBm
– Transmit Power: <20dBm (EIRP)
– Wireless Modes: Ad-Hoc / Infrastructure mode
OTHERS
– Package Contents: Wireless Adapter Archer T2U, Resource CD, Quick Installation Guide
– System Requirements: Windows 8 (32/64bits), Windows 7 (32/64bits), Windows XP (32/64bits)
– Environment:
* Operating Temperature: 0C – 40C (32F – 104F)
* Storage Temperature: -40C – 70C (-40F – 158F)
* Operating Humidity: 10%-90% non-condensing
* Storage Humidity: 5%-90% non-condensing
