Features
– 100% Data filtering rate eliminates all error packets
– Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode
– Non-blocking switching architecture forwards and filters packets at full wire-speed for maximum throughput
– 96Gbps Switching Capacity
– Auto MDI/MDIX eliminates the need for crossover cables
– Supports MAC address auto-learning and auto-aging
– Support the port N-Way Auto-Negotiation, Store and Forward.
– Compact size design for desktops, Rackmountable
– Plug and Play design simplifies installation
Specifications
HARDWARE SPECIFICATIONS
– Interface: 48× 10/100/1000Mbps RJ45 ports (AUTO Negotiation/AUTO MDI/MDIX)
– Mac Address Table: 8K
– External Power Supply: 100-240VAC, 50/60Hz
– Dimensions (W×D×H): 440×360×44 mm
SOFTWARE SPECIFICATIONOS
– Transfer Method: Store and Forward
– Advanced Functions:
* 802.3X Flow Control, Back Pressure
* Auto-Uplink Every port
OTHER FEATURES
– Operating Temperature: 0C – 40C (32F – 104F)
– Storage Temperature: -40C – 70C (-40F – 158F)
– Operating Humidity: 10-90% non-condensing
– Storage Humidity: 5-90% non-condensing
