Features
– Supports WDM Bi-Directional technology, using a single strand of fiber
– TX: 1550nm / RX: 1310nm
– Internal +3.3V Power Supply
– In pairs with TL-SM321B
– Plug-and-Play
– Suitable: MC220L, TL-R4199G/4299G, TL-SG3109, TL-SL3428/3452, TL-SG2109WEB/2216WEB/2224WEB, TL-SL2210WEB/2218WEB/2428WEB/2452WEB, TL-SL1351 and the other equivalent devices
Specifications
– Standards and Protocols: IEEE 802.3z, CSMA/CD, TCP/IP
– Power Supply: 3.3V
– Cabel: Single-mode Fiber
– Fyber Type: 9/125 um Single-mode
– Max. Cable Length: 10km
– Data Rate: 1.25Gbps
– Port Type: LC
– Wave Length: TX: 1550nm / RX: 1310nm
– Safety & Emission: FCC, CE
– Environment:
* Operating Temperature: 0C-70C (32F-158F)
* Storage Temperature: -40C-80C (-40F-176F)
* Operating Humidity: 10% – 90% non-condensing
* Storage Humidity: 5% – 90% non-condensing
