– Designed with both leisure and work in mind, the entry-level 2-bay DS223 has all the tools you need to create an intuitive and secure platform to centralize, organize, and share your data.
Leverage the license-free, built-in solutions available in Synology DiskStation Manager (DSM) to create your own private cloud, access files from any device, and work
efficiently on business projects with clients and collaborators.
– Consolidate files from various sources into your own private cloud. The DS223 keeps the process simple and offers everything you need to keep your data safe and organized.
Private cloud made easy
– Quickly and easily import data from PCs, Macs, and external storage devices, and keep all your devices in sync for smoother file management.
Access from any device
– Get to your files from PC, Mac, Linux, Chromebook, Android, iOS, or any device equipped with a browser. Keep your data private or easily share it using secure links.
Save storage space
– Enable on-demand mode to download files onto your Windows PC or Mac only when you access them. Pin the most important ones or the ones you access more frequently for convenient offline accessibility.
Integrate with the cloud
– Sync files between your private cloud and public cloud services, including Google Drive, Dropbox, and Microsoft OneDrive. Retain local copies of your cloud data for centralized management and data ownership.
Sync across locations
– Say goodbye to long waits while downloading or uploading files. Continuously synchronize content between two Synology devices to enable fast local access at any location, no matter the amount of data.
Sync across locations
– Say goodbye to long waits while downloading or uploading files. Continuously synchronize content between two Synology devices to enable fast local access at any location, no matter the amount of data.
CPU
– CPU Model: Realtek RTD1619B
– CPU Quantity: 1
– CPU Architecture: 64-bit
– CPU Frequency: 4-core 1.7 GHz
– Hardware Encryption Engine: Yes
Memory
– System Memory: 2 GB DDR4 non-ECC
Storage
– Drive Bays: 2
– Compatible Drive Type:
* 3.5″ SATA HDD
* 2.5″ SATA SSD
– Hot Swappable Drive: Yes
External Ports
– RJ-45 1GbE LAN Port: 1
– USB 3.2 Gen 1 Port: 3
– USB / SD Copy: Yes
File System
– Internal Drives:
* Btrfs
* EXT4
– External Drives:
* Btrfs
* EXT4
* EXT3
* FAT
* NTFS
* HFS+
* exFAT
Appearance
– Size (Height x Width x Depth): 165 mm x 108 mm x 232.7 mm
– Weight: 1.28 kg
Others
– System Fan: 92 mm x 92 mm x 1 pcs
– Fan Speed Mode:
* Full-Speed Mode
* Cool Mode
* Quiet Mode
– Brightness Adjustable Front LED Indicators: Yes
– Power Recovery: Yes
– Noise Level: 14.6 dB(A)
– Scheduled Power On / Off: Yes
– Wake on LAN / WAN: Yes
– Power Supply Unit / Adapter: 60 W
– AC Input Power Voltage: 100V to 240V AC
– Power Frequency: 50/60 Hz, Single Phase
– Power Consumption:
* 17.343 W (Access)
* 4.08 W (HDD Hibernation)
– British Thermal Unit:
* 59.19 BTU/hr (Access)
* 13.92 BTU/hr (HDD Hibernation)
Temperature
– Operating Temperature: 0°C to 40°C (32°F to 104°F)
– Storage Temperature: -20°C to 60°C (-5°F to 140°F)
– Relative Humidity: 5% to 95% RH
Certification
* FCC
* CE
* BSMI
* VCCI
* RCM
* UKCA
* EAC
* CCC
* KC
Environment
– RoHS Compliant
– Packaging Content
* Main Unit X 1
* Accessory Pack X 1
*AC Power Adapter X 1
* AC Power Cord X 1
* RJ-45 LAN Cable X 1
* Quick Installation Guide X 1
Optional Accessories
– 3.5″ SATA HDD: HAT5300
– 2.5″ SATA SSD: SAT5210
– VisualStation: VS360HD
– Surveillance Device License Pack
