Model
FNSW-1601
Standard Compliance
IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX
10/100Base-TX Ports
16
Network Speed
TP: Auto-Negotiation, 10/20Mbps, 100/200Mbps
Switching Architecture
Store & Forward
Filtering / Forwarding Rate
100Mbps: 148800 packets / second
10Mbps : 14880 packets / second
MAC entry
8K
LED Indicators/port
2 (Link/Act, 100Mbps)
Data Buffer
512KB
Power Supply
100~240VAC auto-sensing
Operation Environment
Temperature: 0~50 degree C (operating)
Humidity: 0~90%, non-condensing
Dimension (W x D x H)
444 x 120 x 44 mm
Network Media
100Base-TX: RJ-45 STP/UTP, Category 5 cable
10Base-T: RJ-45 STP/UTP, Category 3~5 cable
Certification
FCC class A, CE
