DEVICE PROTECTION
– PoE Adapters are highly reliable, and when used with Ubiquiti TOUGHCable, they provide earth grounding and surge protection to help protect against electrostatic discharge (ESD) events
CONVENIENT WALL-MOUNTING
– Wall-mountable using the optional wall-mount brackets
SEAMLESS airGateway COMPATIBILITY
– Work with the airGateway to bridge airMAX connections to Wi-Fi at customer locations
Specification
– Output Voltage: 24VDC @ 0.5A
– LAN Activity Indicator: No
– Gigabit LAN Port: Yes
– Remote Reset Capability: Yes
– Reset Button: Yes
– Input Voltage: 90-260VAC @ 47-63 Hz
– Input Current:
* 0.3A @ 120VAC
* 0.2A @ 240VAC
– Inrush Current:
* <30A Peak @ 120VAC
* <60A Peak @ 230VAC
– Efficiency: 75+ %
– Output Ripple: 1% max.
– Switching Frequency: 50 kHz
– Line Regulation: +/- 1%
– Load Regulation: +/- 3%
– 2-Pair Powering: Pins 4, 5 (+) and Pins 7, 8 (-)
– Operating Temperature: 0C to 40C (32F to 104F)
– Storage Temperature: -30C to 70C (-22F to 158F)
– Operating Humidity: 35 to 95% Noncondensing
– AC Connector: IEC-320 C6
– Data IN / POE: RJ45 Shielded Socket
– Surge Protection: Difference and Common Mode
– Clamping Protection: 11V Data, 60V Power
– Max. Surge Discharge: 1500A (8/20 µs) Power
– Peak Pulse Current: 36A (10/1000 µs) Data
– Shunt Capacitance: <5 pF data
– Dimensions: 87×44×29 mm
– Weight: 99.4 g
