2K 5MP Head-to-Toe View
– D235’s 4:3 aspect ratio captures a 180° field of view with high resolution.
Smart AI Detection and Notification
– Smart AI identifies people, pets, and packages, notifying users as needed.
360 Days of Use
– Tapo D235 supports being used for 360 days. No more worrying about missing what happens outside your door.
Two-Way Audio
– Enables communication through a built-in microphone and speaker.
Powered by Hardwire or Battery
– Place the doorbell anywhere you need.
Specifications
CAMERA
– Image Sensor: 1/2.7“ Progressive Scan CMOS Sensor
– Lens: Focal Length: 1.18mm
– Aperture: F1.8
– Field of View: 170.6° (Horizontal), 140.1° (Vertical)
– Night Vision: 850 nm IR LED (33 ft / 10 m)
– Full-Color: Night Vision
– Lighting: Built-in Spotlights
– Interface & Button:
• 1× RESET /SYNC Button
• 1× Doorbell Button
• 1× Anti-Theft Button
• 1× Power ON/OFF Button
VIDEO & AUDIO
– Maximum Resolution: 2K 5MP (2560 × 1920px)
– Frame Rate: 15/20 fps
– Digital Zoom: 16x
– Video Compression: H.264
– Live View: Yes
– Image Enhancement
• 3DNR
• WDR
– Audio Input & Output: Built-in Microphone and Speaker
– Audio Communication: Two-Way Audio with Noise Cancellation
– Siren Volume: 98dB (Level measured at 4-inch/10-cm distance)
STORAGE
– Local Storage: MicroSD Card Slot on Hub (Up to 512 GB)
– Cloud Storage: Tapo Care Cloud Storage Services (Subscription required)
DETECTION and NOTIFICATIONS
Sensor:
• Single PIR Motion Sensor (FOV: 130° horizontal)
• One Ambient Light Sensor
– AI Detection
• Motion Detection
• Person Detection
• Pet Detection
• Vehicle Detection
• Package Detection
– Activity Zones: Yes – Only works with Motion Detection.
– Output Notification
• System Notification
• System Notification with Snapshot (Tapo Care Services)
NETWORK
– Network Connectivity: IEEE 802.11b/g/n, 2.4 GHz Wi-Fi
SECURITY
– Security
• On-Device Machine Learning
• 128-bit AES Encryption with SSL/TLS
• WPA/WPA2-PSK
POWER
– Power Source:
• 10000 mAh Built-in Rechargeable Lithium-ion Battery
• Hardwire charge
• Hardwire supply
– Input Voltage: Doorbell Battery Pack Adapter Input: 100-240 V, 50/60 Hz
– Output Voltage: Doorbell Battery Pack Adapter Output: 5.0 V, 2.0 A
GENERAL
– Smart Integration: Google Assistant, Amazon Alexa
– Weather Resistance: IP66
– System Requirements: Tapo App: iOS 9.0 or higher, Andriod 4.4 or higher –
– Mounting Options
• Stick to a Wall
• Mount to a Wall
– Operating Temperature: -20?~45?
– Storage Temperature: -20?~45?
– Operating Humidity: 10%~90% RH, Non-condensing
– Storage Humidity: 0~90% RH, Non-condensing
– Charging Temperature: 0-45?
– Dimensions
• Doorbell Dimensions: 5.91 × 1.97 × 1.52 in (150 × 50 × 38.4 mm)
• Chime Dimensions: EU Version: 2.87 × 2.15 × 1.89 in (73×54.6×48 mm)
– Package Contents
• Tapo Video Doorbell × 1
• Tapo Chime × 1
• Mounting Template × 1
• Mounting Bracket × 1
• Vertical Mounting Wedge× 1
• Horizontal Mounting Wedge × 1
• USB Adapter Cable × 1
• Jumper for Existing Chime × 1
• Extension Wires × 2
• Mounting Screws and Anchors × 3
• Hardwire Installation Screws × 2
• Doorbell Detaching Pin × 1
• Mounting Wedge Screws × 5
• 3M Adhesive × 1
• Foam Pad × 1
• Wire Nuts × 2
• Quick Start Guide
– Certifications: CE, RoHS, RCM,R-NZ,FCC, EAC, Triman, UKCA
