Features
– IEEE 802.3af compliant
– Delivers power up to 100 meters
– Auto-determine the necessary power requirements
– Plug-and-Play, requires no configuration
– External power adapter supply
Specifications
– Standards and Protocols:
* IEEE 802.3, 802.3u, 802.3af
* CSMA/CD, TCP/IP
– Basic Function:
* Compatible with IEEE 802.3af compliant PDs
* Delivers power up to 100 meters
* Auto-determine the necessary power requirements
* Plug-and-Play
– Ports:
* LAN Port – 1× 10/100M Auto-Negotiation RJ45 port (Auto MDI/MDIX)
* PoE Port – 1× 10/100M Auto-Negotiation RJ45 port (Auto MDI/MDIX)
– Network Media:
* 10BASE-T: UTP category 3, 4, 5 cable (max. 100m)
* EIA/TIA-568 100 Ohm STP (max. 100m)
* 100BASE-TX: UTP category 5, 5e cable (max. 100m)
* EIA/TIA-568 100 Ohm STP (max. 100m)
– LED Indicator: PWR
– Safety & Emission: FCC, CE
– Dimensions (W×D×H): 81×52×24 mm
– Environment:
* Operating Temperature: 0C – 40C (32F – 104F)
* Storage Temperature: -40C – 70C (-40F – 158F)
* Operating Humidity: 10% – 90% non-condensing
* Storage Humidity: 5% – 90% non-condensing
– Power Output: 15.4W (Max. 48VDC)
