Features
– Light weight for taking conveniently
– Vehicle charger support
– Continuing printing when battery is being charged
Application Scenarios
– Logistics
– Take Away
– Retail
– Storage
– Catering
– Garment
Specifications
– Print Method: Thermal line
– Resolution: 8 dots/mm ( 203dpi ), 384 dots/line
– Print Speed: 62mm/s
– Effective Print Width: 48mm
– Paper Width: 57.5+0.5mm
– Self-defined Character: Yes
– Character Set: ASCII, GB18030(Chinese), BIG5, GB12345, Codepage
– Print Font Font:
• A: 8×16(16×16), Font B: 9×24, Font C: 12×24(24%x24)
• 1D:UPC-A, UPC-E, EAN-13, EAN-8, CODE39, ITF25,
– Barcode: CODEBAR, CODE93, CODE128,2D: PDF417, QR CODE, DATA MATRIX
– Interface: USB/Serial/USB+Bluetooth(2.0/4.0)/Serial+USB+Bluetooth(2.0/4.0)
– SDK: Symbian/Windows/Blackberry/Linux/Android/iOS
– Battery: 7.4V/1500mAh Rechargeable Li-ion Battery
– Charger: SV/1A
– TPH: 50KM
– Paper Type: Normal Thermal Paper
– Paper Thickness: 0.06-0.08mm
– Paper Roll: Diameter 40mm (MAX)
– Paper Supply Method: Drop-in Easy Loading
– Paper Cutting Method: Manual
– Dimension: 106.5mmx78mmx47mm_ (LxWxH)
– Weight: 190g(NO Paper)
– Operation Temp/Humidity: 0°C ~ 50°C/10% ~ 80%
– Storage Temp/Humidity: -20°C ~ 60°C /10% ~ 90%
