NFO Cable roller 80mm

NFO Cable roll 80mm – designed for hanging overhead cables. The roller wheel is made of aluminum and is mounted on a closed ball bearing, which prevents dirt and sand from entering during operation. The remaining elements of the roller are made of steel parts. The roller is designed for installation on poles and supporting structures. The upper, opening part of the roller makes it easier to place the cable on the wheel with bearings Material thickness: 3.69mm Total dimensions: 80mm x 70mm x 260mm External dimensions. hook: 15mm x 70mm x 89mm Inner diameter. hook: 24.70mm Shaft dimensions: 40mm x 182mm Roll dimensions: 80mm x 34mm Internal diameter of the cable roll: 22.80mm Weight: 1 kg Load capacity: 5kN
