Specifications
PERFORMANCE
– Processor: Intel Core i5-1335U, 10C (2P + 8E) / 12T, P-core 1.3 / 4.6GHz, E-core 0.9 / 3.4GHz, 12MB
– Graphics: Integrated Intel Iris Xe Graphics
– Chipset: Intel SoC Platform
– Memory: 8GB Soldered DDR4-3200 + 8GB SO-DIMM DDR4-3200
– Memory Slots: One memory soldered to systemboard, one DDR4 SO-DIMM slot, dual-channel capable
– Max Memory: Up to 40GB (8GB soldered + 32GB SO-DIMM) DDR4-3200
– Storage: 512GB SSD M.2 2242 PCIe 4.0×4 NVMe Opal 2.0
– Storage Support: Up to two drives, 2x M.2 SSD
• M.2 2242 SSD up to 1TB
– Storage Slot: Two M.2 slots
• One M.2 2242 PCIe 3.0 x4 slot
• One M.2 2242 PCIe 4.0 x4 slot
– Card Reader: No card reader
– Optical: None
– Audio Chip: High Definition (HD) Audio, Synaptic CX11880 codec
– Speakers: Stereo speakers, 2W x2, Dolby Atmos
– Camera: FHD 1080p + IR Hybrid with Privacy Shutter
– Microphone: 2x, Array
– Battery: Integrated 57Wh
– Power Adapter: 65W USB-C (3-pin)
DESIGN
– Display: 14″ WUXGA (1920×1200) IPS 300nits Anti-glare, 45% NTSC
– Touchscreen: None
– Keyboard: Backlit, Croatian
– Case Color: Graphite Black
– Case Material: Aluminium (Top), Aluminium (Bottom)
– Dimensions (WxDxH): 313 x 219.3 x 17.99 mm (12.32 x 8.63 x 0.71 inches)
– Weight: Starting at 1.43 kg (3.15 lbs)
SOFTWARE
– Operating System: Win 11 Pro
– Bundled Software: None
CONNECTIVITY
– Ethernet: 100/1000M (RJ-45)
– WLAN + Bluetooth: Wi-Fi 6, 802.11ax 2×2 + BT5.1
– WWAN: None
– SIM Card: None
– NFC: None
– Standard Ports
• 1x USB 2.0
• 1x USB 3.2 Gen 1 (Always On)
• 1x USB-C 3.2 Gen 2 (support data transfer, Power Delivery 3.0 and DisplayPort 1.4)
• 1x Thunderbolt 4 / USB4 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort 1.4)
• 1x HDMI 2.1, up to 4K/60Hz
• 1x Headphone / microphone combo jack (3.5mm)
• 1x Ethernet (RJ-45)
– Docking: Various docking solutions supported via Thunderbolt™ or USB-C.
*For more compatible docking solutions, please visit Docking for ThinkPad E14 Gen 5 (Intel)
SECURITY & PRIVACY
– Smart Card Reader: None
– Security Chip: Discrete TPM 2.0 Enabled
– Fingerprint Reader: Touch Style, Integrated in Power Button
– Physical Locks: Kensington Nano Security Slot, 2.5 x 6 mm
– Other Security
• IR camera for Windows Hello (facial recognition)
• Camera privacy shutter
MANAGEABILITY
– System Management: Non-vPro
SERVICE
– Warranty: 3Y
ACCESSORIES
– Bundled Accessories: None
CERTIFICATIONS
– Green Certifications
• ErP Lot 6
• ErP Lot 26
• FSC certified package
• RoHS compliant
• TCO Certified 9.0
– Other Certifications
• TÜV Rheinland Low Blue Light (Software Solution)
• Mil-Spec Test: MIL-STD-810H military test passed
