– It can be installed in the wild environment for concealed monitoring and capture, and can detect the living habits and wild animals to provide guidance for nimal protection research
Features
– High-sensitivity PIR detector, accurate detection of wild animals, high-definition image acquisition, detection range can cover horizontal 102°
– Ultra-low power consumption: Support sleep mode and full power consumption mode, in sleep mode, the standby time can be up to 180 days (10 snapshots a day)
– Ultra-low illumination, providing star-level monitoring effect, providing clearer video and snapshot effects
– The highest resolution can reach 2560 × 1440 @25 fps, and real-time image can be output
– Support BLC, HLC,DWDR, adapt to different monitoring environments
– 15 m IR Range
– Support 256 GB Micro SD/Micro SDHC/Micro SDXC
– Support: LTE-TDD/LTE-FDD/TD-SCDMA/UMTS/EVDO/CDMA 1×
– Build-in GPS
– Build-in microphone
Specification
CAMERA
– Image Sensor: 1/3″ Progressive Scan CMOS
– Min. Illumination:
* Color: 0.005 Lux @ (F1.2, AGC ON)
* B/W: 0.001 Lux @ (F1.2, AGC ON), 0 Lux with IR
– Shutter Speed: 1/3 s to 1/100,000 s
– Wide Dynamic Range: Digital WDR
– Day & Night: IR cut filter
LENS
– Lens Type & FOV: 2.8 mm, horizontal FOV 102°, vertical FOV 55°, diagonal FOV 122°
– Aperture: F1.4
– Lens Mount: M12
ILLUMINATOR
– IR Range: Up to 15 m
– Wavelength: 940 nm
– Smart Supplement Light: Yes
VIDEO
– Max. Resolution: 2688×1520
– Main Stream:
* 50 Hz: 25 fps (2688×1520, 1920×1080, 1280×720)
* 60 Hz: 30 fps (2688×1520, 1920×1080, 1280×720)
– Sub Stream:
* 50 Hz: 25 fps (640×480, 640×360)
* 60 Hz: 30 fps (640×480, 640×360)
– Video Compression:
* Main stream: H.265
* Sub-stream: H.265/H.264/MJPEG
– Video Bit Rate: 32 Kbps to 16 Mbps
– H.264 Type: Main Profile/High Profile
– H.265 Type: Main Profile
– Bit Rate Control: CVR/BVR
– Scalable Video Coding (SVC): H.264 and H.265 encoding
– Region of Interest (ROI): 4 fixed area for main stream and sub-stream
AUDIO
– Environment Noise Filtering: Yes
– Audio Sampling Rate: 8 KHz/16 KHz/32 KHz/44.1 KHz/48 KHz
– Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3
– Audio Bit Rate: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32~192 Kbps(MP2L2)
– Audio Type: Mono
NETWORK
– Simultaneous Live View: Up to 20 channels
– API: Open Network Video Interface (PROFILE S, PROFILE G), ISAPI, SDK, Ehome
– Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour, UDP
– User/Host: Up to 32 users / 3 user levels: administrator, operator and user
– Network Storage:
* NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
* Together with high-end Hikvision memory card, memory card encryption and health detection are supported
– Client: iVMS-4200, Hik-Connect
– Web Browser:
* Plug-in required: IE 8+, Chrome 41.0 to 44, Firefox 30.0 to 51, Safari 8.0 to 11
* Plug-in free: Chrome 45.0+, Firefox 52.0+
MOBILE COMMUNICATION
– 4G Frequency:
* LTE-TDD Band 38/39/40/41
* LTE-FDD Band 1/3/5
* TD-SCDMA Band 34/39
* UMTS 1/8
* EVDO BC0
* CDMA 1x BC0
– 4G Standard: LTE-TDD/LTE-FDD/TD-SCDMA/UMTS/EVDO/CDMA 1×
– Day/Night Switch: Day, Auto
– Picture Overlay: LOGO picture can be overlaid on video with 128 × 128 24bit bmp format
– Image Enhancement: BLC, HLC, Defog, 3D DNR
– Image Parameters Switch: Yes
– Image Settings: Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
– SNR: ? 52 dB
– Privacy Mask: Yes
PIR
– PIR Range: 15 m
– PIR Angle: Horizontal: 90°
SATELLITE POSITIONING
– GPS Detection: Support GPS and searching longitude and latitude of the device
INTERFACE
– Audio: 1 built-in microphone
– RS-232: 1 four-core 1.5 mm serial port
– On-board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC/TF card, up to 256 GB
– Hardware Reset: Yes
– Ethernet Interface: 1 six-core 1.25 mm interface (it can be transferred as 1 12 VDC coaxial interface and 1 RJ 45 10 m/100 m self-adaptive Ethernet port)
EVENT
– Smart Event: Intrusion detection, line crossing detection, region entrance detection, region exiting detection
– Linkage: Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture, sending message
GENERAL
– Online Upgrade: Yes
– Dual Backup: Yes
– Firmware Version: V5.5.110
– General Function: One-key reset, anti-banding, heartbeat, password protection, privacy mask, watermark, IP address filter
– Software Reset: Yes
– Material: Plastic
– Screw Material: SUS304
– Camera Dimension:
* With antennas folded: 171.5×139.7×86.9 mm
* With antennas extending: 283.4×139.7×86.9 mm
– Camera Weight: Approx. 0.61 kg
– Storage Conditions: -20 °C to 60 °C (-22 °F to 140 °F).Humidity 95% or less (non-condensing)
– Startup and Operating Conditions:
* C1/C2: -20 °C to 60 °C (-22 °F to 140 °F).Humidity 95% or less (non-condensing)
* C0: -10 °C to 60 °C (-22 °F to 140 °F).Humidity 95% or less (non-condensing)
– Power Supply:
* C1/C2: USB Type-C (5V, 2A)
* C0: dry cell (10, 5AA dry cell, 1.5 V)
– Power Consumption and Current: 6 to 15 VDC, 0.82 to 0.33 A, max. 4.9 W
– Power Interface:
* C1/C2: pin
* C0: shrapnel (5AA dry cell)
BATTERY
– Battery Type:
* C1/C2: chargeable lithium battery
* C0: 5AA dry cell
– Capacity: C1/C2: 9.4 Ah
– Operating Temperature:
* C1/C2: -20°C – 60°C
* C0: -10°C – 60°C
– Battery Voltage:
* C1/C2: Rated voltage: 7.2 VDC, Charging voltage: 8.4 VDC, Discharging cut-off voltage: 5.6 VDC
* C0: Rated voltage: 15 VDC, Discharging cut-off voltage: 8 VDC
– Cycle Lifetime: Cycle lifetime is calculated under the condition that the camera captures 10 times per day (9 times during the day and 1 time at night)
* C1/C: 80 days
* C0: 22 days
