GENERAL SPECIFICATIONS
– Platform: Desktop
– Product Family: AMD Ryzen Processors
– Product Line: AMD Ryzen 9 Processors
– No. of CPU Cores: 12
– No. of Threads: 24
– Max. Boost Clock: Up to 5.4GHz
– Base Clock: 3.7GHz
– L1 Cache: 768KB
– L2 Cache: 12MB
– L3 Cache: 64MB
– Default TDP: 65W
– Processor Technology for CPU Cores: TSMC 5nm FinFET
– Unlocked for Overclocking: Yes
– CPU Socket: AM5
– Supporting Chipsets
* X670E
* X670
* B650E
* B650
– Thermal Solution (PIB): AMD Wraith Prism
– Max. Operating Temperature (Tjmax): 95°C
CONNECTIVITY
– PCI Express Version: PCIe 5.0
– System Memory Type: DDR5
– Memory Channels: 2
– Max Memory Speed:
* 2x1R DDR5-5200
* 2x2R DDR5-5200
* 4x1R DDR5-3600
* 4x2R DDR5-3600
GRAPHICS CAPABILITIES
– Graphics Model: AMD Radeon Graphics
– Graphics Core Count: 2
– Graphics Frequency: 2200 MHz
– GPU Base: 400 MHz
PRODUCT IDs
– Product ID Boxed: 100-100000590BOX
