GENERAL SPECIFICATIONS
– Platform: Desktop
– Product Family: AMD Ryzen Processors
– Product Line: AMD Ryzen 5 Processors
– No. of CPU Cores: 6
– No. of Threads: 12
– Max. Boost Clock: Up to 5.1GHz
– Base Clock: 3.8GHz
– L1 Cache: 384KB
– L2 Cache: 6MB
– L3 Cache: 32MB
– Default TDP: 65W
– Processor Technology for CPU Cores: TSMC 5nm FinFET
– Unlocked for Overclocking: Yes
– CPU Socket: AM5
– Supporting Chipsets
* X670E
* X670
* B650E
* B650
– Thermal Solution (PIB): AMD Wraith Stealth
– Max. Operating Temperature (Tjmax): 95°C
– OS Support
* Windows 11 – 64-Bit Edition
* Windows 10 – 64-Bit Edition
* RHEL x86 64-Bit
* Ubuntu x86 64-Bit
* Operating System (OS) support will vary by manufacturer
CONNECTIVITY
– PCI Express Version: PCIe 5.0
– System Memory Type: DDR5
– Memory Channels: 2
– Max Memory Speed:
* 2x1R DDR5-5200
* 2x2R DDR5-5200
* 4x1R DDR5-3600
* 4x2R DDR5-3600
GRAPHICS CAPABILITIES
– Graphics Model: AMD Radeon Graphics
– Graphics Core Count: 2
– Graphics Frequency: 2200 MHz
– GPU Base: 400 MHz
PRODUCT IDs
100-100001015BOX
