Opis
Dostupnost: Po narudžbi
Specifikacije:
Throughput
– Increase network performance with 10GbE connectivity
Flexibility
– Easy integration to existing deployments
Compatibility
– Designed for maximum performance and reliability in Synology systems
Specifications
Hardware Specifications
– Host Bus Interface: PCIe 3.0 x8
– Bracket Height: Low Profile and Full Height
– Size (Height x Width x Depth): 68.9 mm x 167.7 mm x 14.7 mm
– Operating Temperature: 0°C to 40°C (32°F to 104°F)
– Storage Temperature: -20°C to 60°C (-5°F to 140°F)
– Relative Humidity: 5% to 95% RH
Network
– IEEE Specification Compliance
• IEEE 802.3x Flow Control
– IEEE 802.3ad Link Aggregation
– IEEE 802.3ab Gigabit Ethernet
– IEEE 802.3an 10Gbps Ethernet
– Data Transfer Rates: 10 Gbps/1 Gbps
– Supported Features
• TCP Segmentation Offload (TSO)
• Receive Side Scaling (RSS)
• Generic Segmentation Offload (GSO)
• 1.5 – 9 KB Jumbo Frame
• TCP/UDP Checksum Offload
• Transmit side scaling (TSS)
• SR-IOV
• Large receive offload (LRO)
Compatibility
– Applied Models
• FS series:FS6400, FS3600, FS3410, FS3400, FS2500
• HD series:HD6500
• SA series:SA6400, SA3610, SA3600, SA3410, SA3400D, SA3400, SA3200D
• UC series:UC3400, UC3200
• 23 series:RS2423RP+, RS2423+, DS1823xs+
• 22 series:RS822RP+, RS822+, DS3622xs+, DS2422+
• 21 series:RS4021xs+, RS3621xs+, RS3621RPxs, RS2821RP+, RS2421RP+, RS2421+, RS1221RP+, RS1221+, DS1821+, DS1621xs+, DS1621+
• 20 series:RS820RP+, RS820+
• 19 series:RS1619xs+, DS2419+II, DS2419+, DS1819+
• 18 series:RS3618xs, RS2818RP+, RS2418RP+, RS2418+
• 17 series:DS3617xs
Jamstvo: 36 mjeseci
Kod dobavljača: E10G30-T2
